QUALITY SERIES 2 PUMPS | OPERATION, INSTALLATION & WARRANTY INFORMATION
COMPLETE PUMP SUPERFLO 2
NO. COMPONENT PART NO. DESCRIPTION QTY
1 500-6044 PUMP CLAMP COMPLETE 1
2 500-6083 PUMP LID KNOB 1
3a 110-5170 SERIES 2 PUMP UNION COMPLETE 50mm 2
3b 110-5171 SERIES 2 PUMP UNION COMPLETE 63mm 2
4 110-5123 SERIES 2 PUMP UNION O-RING 2
5 500-6097 PUMP LID 1
6 500-6095 PUMP LID O-RING 1
7 500-6031 PUMP BASKET SUPERFLO 1
8 500-6326 SERIES 2 PUMP DIFFUSER O-RING 1
9 500-6053 PUMP DIFFUSER SCREW M4X25 3
10 500-6322 SERIES 2 PUMP DIFFUSER 1
11a 500-6331 SERIES 2 PUMP IMPELLER WITH INSERT 0,6kW 1
11b 500-6335 SERIES 2 PUMP IMPELLER WITH INSERT 0,75kW 1
11c 500-6402 SERIES 2 PUMP IMPELLER WITH INSERT 1,1kW 1
12 500-6165 SERIES 2 PUMP SHAFT SEAL 3/4” 1
13 500-6062 PUMP FLANGE O-RING 1
14 500-6321 SERIES 2 PUMP SEAL PLATE 1
15 500-6325 FLANGE BOLT SS M6X40 8
16a 500-1058 BARESHAFT MOTOR 0,6kW 230V 1
16b 500-2061 BARESHAFT MOTOR 0,75kW 230V 1
16c 500-3061 BARESHAFT MOTOR 1,1kW 230V 1
17 500-6327 FLANGE BOLT SS M8X30 4
18 500-6280 SERIES 2 PUMP BODY 1
19 500-6398 SERIES 2 PUMP FOOT PIECE 1
20a 500-6213 WEDGE 0,6kW / 0,75kW 1
20b 500-6227 WEDGE 1,1kW 1
