-2-
TEV LIMITED - CHILLED WATER HIGH WALL UNITS
The 973 series consists of CWM chilled water high wall units using remote wired controllers and CWM L chilled water
high wall units using infrared controllers.
PART NUMBERS - CWM (L) INDOOR UNITS
CWM CWM 55 CWM 75 CWM 105
97300001 97300002 97300003
CWM L CWM L 55 CWM L 75 CWM L105
97300004 97300005 97300006
UNPACKED DIMENSIONS AND WEIGHTS
Model
CWM (L)
55 75 105
HEIGHT mm 350 350 350
WIDTH mm 1200 1500 1800
DEPTH mm 223 223 223
WEIGHT kg 19 23 27
PACKED DIMENSIONS AND WEIGHTS
Model
CWM (L)
55 75 105
HEIGHT mm 295 295 295
WIDTH mm 1270 1570 1870
DEPTH mm 410 410 410
WEIGHT kg 23 28 33
FEATURES/ACCESSORIES
CWM CWM L
Top air discharge
STD STD
Adjustable air deflection
STD STD
Long life washable filter
STD STD
3 fan speeds
STD STD
Electric heating
** **
Remote hard wired control
* ---
Remote temperature sensor
** ---
Programmable timer
** ---
Remote infrared control
--- *
Gravity drain
STD STD
5m high condensate pump
** **
Pipe thermostat (2 pipe H/C)
** **
Low Pressure Hot Water coil
**
2 or 4 port valves
**
STD = Standard * = factory option ** = site accessory ---- = not available
.
For group control systems, contact TEV Ltd. Technical Sales Department.
