EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
ANTENNALEADIN WIRE
ANTENNA
DISCHAGRE UNIT
(NEC SECTIO N 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250,RARTH)
GROUND
CLAMP
ELEC TRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
27) Explanation of symbol, marking, signal lamp or similar means indicate that apparatus
is completely disconnected from the mains. This equipment is a Class II or double
insulated electrical appliance. It has been designed in such a way that it does not require a
safety connection to electrical earth.
28) Correct Disposal of this product. This marking indicates that this product should
not be disposed with other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer where the product was purchased.
26) Where the mains plug is used as the disconnect device, the disconnect device shall
remain readily operable.
