TMS STRING PINSPOTTER OWNER’S MANUAL

400-051-010-01 Rev. Date: 6/17 Page 5-62

051-070-023 – Single Division Platform Assembly

Item

Part Number

Description

051-070-050

SINGLE DIVISION PLATFORM

051-070-021

TUBE CLAMP

7012-003118-350

CB 5/16-18 X 3.50 GR5 ZN

7038-003118-000

KN 5/16-18 ZN
