F
27
MOD. 0980 - 0990 - 0995
QUICK MILL
1. Die-casted water recirculation unit
2. Steam pressure gauge (mod. 0980-0990)
3. Pump pressure gauge (mod. 0980-0990)
4. RED light: heating
5. Main switch
6. Coffee dispensing lever
7. GREEN light: machine on
8. Steam tap
9. Hot water tap
10. Steam nozzle with anti-burn insulator
11. Water nozzle with anti-burn insulator
12. GREEN light: machine ready
13. Drip tray
14. Cup resting grill
15. Cup warming cover
16. Manomètre à double échelle (mod. 0995)
1. 1 cup filter holder complete with filter
2. 2 cup filter holder complete with filter
3. Measuring cup / presser
4. Blind filter
4. DESCRIPTION OF PARTS
ACCESSORIES NOT SHOWN IN FIGURE
