16
GB
AFR 700/1000/1400W - REV012A
MAINTENANCE
44
45
46
47
48
49
42
43
40
37
35
36
41
40
33
31
38
39
34
32
37
35
36
30
30
38
39
27
26
15
16
17
18
24
23
28
1
19
4
2
6
14
5
7
5
13
3
25
29
15
11
12
11
10
9
8
19
20
21
22
50
POS.
DESCRIPTION CODE
1 Bent anchor winch lever ZSLMSHR10000
2 Gypsy cover SPMSGB100R02
3 Bush series “AL” SGMSDCPAL100
4 Drum windlass “AL” 1000W SPMSE10ALR01
5 Clutch cone MSF100000000
6A Gypsy 6 mm ZSB100600000
6B Gypsy 8 mm-5/16" ZSB1008516R4
6C Gypsy 10 mm-3/8" ZSB1010380AR
7 Magnet KPMC08060000
8 Spring washer MBR254025X00
9 Oil seal PGPRL2547700
10 Internal circlip MBAN4717Y000
11 External circlip MBAE2520Y000
12 Bearing MBJ60052RS10
13 Short shaft MSAS10274R30
14 Long shaft MSAS10308R30
15 Key MBH080780F00
To Next Page
