BOILER B3 15-80 - REV004B
IT
6
SCHEMA DI COLLEGAMENTO
NEUTRO RETE AC FASE RETE AC
MANOPOLA
REGOLAZIONE
TEMPERATURA
PULSANTE
RIARMO
FASE NEUTRO TERRA
INTERRUTTORE
FUSIBILE
MARRONE
BLU
GIALLO / VERDE
FIG.3
FIG.1
FIG.2
LIQUIDO
RAFFREDDAMENTO
MOTORE
USCITA ACQUA
SANITARIA CALDA
INGRESSO ACQUA
SANITARIA FREDDA
SERBATOIO ACQUA
SANITARIA
AUTOCLAVE
ACQUA
FREDDA
ACQUA CALDA
VASO AD ESPANSIONE
FIG.4
