Q2 Plans - Chapter 17 - Page 17-01
FUEL SYSTEM INSTALLATION
INTRODUCTION
..... The Q2 fuel system consists of a main fuel tank that forms part
of the seat, and a fuel header tank positioned above the passengers'
legs. The carburetor receives fuel by gravity feed from the header
tank. The header tank is filled from the main fuel tank by an
electric fuel pump, with a manual fuel pump as a backup. An overfill
line in the header tank continually re-circulates the excess fuel
pumped by the fuel pump back to the main fuel tank. Each tank has a
separate fuel gauge. In the event of a complete fuel pump failure, a
