Quincy Compressor QOF 2 User Manual

Section VI - Adjustments and servicing procedures
Quincy Compressor 31
Thepurposeofcleaningthecoolingchannelsofascrollelementistopreventthe
coolingchannelstosiltupandassuchreducethecoolingefciency.Areducedcooling
efficiency can lead towards a premature compressor element failure.
Procedure:
1. Stop the compressor and switch off the power.
2. Close the air outlet valve and depressurise the compressor.
3. Removethefanduct:
•Unscrewthe3bolts(1).
•Removeclip(2)(ifapplicable).
•Removefanduct(3).
4. Cleancoolingchannels:
•Removedustfromthecoolingchannels(1)bymeansofairjet(seenextgure).
•Cleanthefanduct(2).
5. Reassemblethefanduct:
•Putthefanductinplace.
•Fitthe3boltsandtheclip.
Theunitisnowagainreadyforuse.

Quincy Compressor QOF 2 Specifications

General

Brand	Quincy Compressor
Model	QOF 2
Category	Air Compressor
Language	English
