7
20Fold Stroller
NOTE: You have the
option of removing the
seat before folding.
Close canopy
(Figure 20).
20
20a
20b
20c
20d
To make the stroller more
compact, you may remove
the wheels. Press the rear
wheel release button to
pull each rear wheel out
(Figure 20c).
Stand at the front of the
stroller. Push the left but-
ton (with ridges), while
using your thumb to slide
the right button (with
arrows) in the direction of
the arrows (and then press
it)
(Figure 20a).
While buttons are still
pressed, push the stroller
down to fold toward front
wheel. Push down as far
as possible and secure the
transport hook to prevent
the stroller from unfolding
during transport
(Figure
20b)
. This may require
some force. However, it
will become easier in time.
Press both front wheel
release buttons to pull the
front fork out of the frame
tube
(Figure 20d).
