20
Wi
Turning on Wi
When the optional Q5 WIFI USB Dongle is inserted, you can surf the Web via Wi-Fi by
using the Web browser.
To turn on Wi, perform the following:
1. Press the ◄ or ► button to select the Wi icon in the media suite menu.
2. Press to enter Wi Settings.
3. Press the ◄ or ► button to select Enable and then press to turn on Wi function.
4. Press the ◄ or ► button to select and then press to search for APs.
5. Press the ▲ or ▼ button to select an AP and then press to connect.
Note:
1. The Wi function is only available with Q5’s optional dongle.
2. Press Page Up on the remote control to return to the top of the function area. From
here, you can refresh the AP list.
3. Press Page Down to move to the bottom of the AP list when in the function area.
Control Interface
The Wi Setting contains the following controls:
ACTION DESCRIPTION
Return to Main Window.
Rescan all APs.
Enable/Disable Wi.
Wi conguration.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Qumi Q5 and is the answer not in the manual?

Qumi Q5 Specifications

General IconGeneral
Resolution1280 x 800 (WXGA)
Brightness500 ANSI Lumens
Contrast Ratio10, 000:1
Projection TechnologyDLP
Lamp Life30, 000 Hours (LED)
Aspect Ratio16:10
Built-in Memory4GB
Light SourceLED
ConnectivityHDMI, USB, Audio Out
Projection Size30" - 90"
Operating SystemNo
Built-in Speaker2W
Battery LifeNo
