R volution PlayerOne 8K - Device Physical Layout; Front Panel Overview; Rear Panel Connectivity Details

42
2
5 6
7
8
1
9 10
1 12
6
1. Wi-Fi Antenna
2. USB 3.0 Host
3. IR IN (IR extenter included)
1. LCD Screen
2.
POWER ON/Sleep
3. USB 2.0 Host
4. Power LED 5. Internal Hard Drive Rack Door
4. Optical Digital Audio Output
5. Analog Audio Output / Restore
6. HDMI 2.1a Output
9. Ground
10. Power ON/OFF
11. Power Input
12. RF Antenna
7. LAN 10/100/1000 (Ethernet)
8. DC Input for External Power Supply 12V ≥3A
Rear View
Front View
1
4
2
3
3
11
5
