R82 Cricket - Technical Specifications: Dimensions; Cricket 1 Dimensions and Measurements; Cricket 2 Dimensions and Measurements

18
support.R82.org
mm (inch)
1 2
Effective seat width
340 (13½”) 395 (15½”)
Effective seat depth
210-310 (8¼-12¼”) 310-430 (12¼-17”)
Backrest height
500 (19¾”) 570 (22½”)
Footrest to seat distance
180-360 (7-14¼”) 225-370 (8¾-14½”)
Leg to seat surface angle
360° 360°
Seat surface height at front edge
500-530 (19¾-21”) 540-580 (21¼-22¼”)
Backrest width, inside
270 (10¾”) 330 (13”)
Backrest width, outside
340 (13½”) 395 (15½”)
Overall width
525 (20¾”) 575 (22¾”)
Length
750 (29½”) 750 (29½”)
Overall height
1000 (39¼”) 1050 (41¼”)
Backrest angle
110 -> 125° 110 -> 125°
Seat plane angle
20° 20°
Armrest to seat distance
160-190 (6¼-7½”) 160-190 (6¼-7½”)
Front location of armrest structure
200 (7¾”) 275 (10¾”)
Minimum turning radius
725 (28½”) 763 (30”)
Folded width
355 (14”) 355 (14”)
Folded height
485 (19”) 485 (19”)
Folded length
760 (30”) 760 (30”)
