UNDERSTANDING BATTERIES AND CONNECTORS
INSTALLING AND WIRING YOUR REAKTOR BRUSHLESS SYSTEM...
Simple • Capable • Safe
Batteries:
The Radient Reaktor ESCs can operate with LiPo/LiFe and NiCd/NiMH (NiXX) batteries
which require different LVC operating modes. It is extremely important to choose the cor-
rect operating mode to work with your batteries. Choosing the wrong charging mode can
cause over-discharge of your LiXX type batteries which could lead to fire or explosion. Be
sure to properly identify the battery chemistry and voltage of every pack before attempt-
ing to use it to ensure the correct settings. Some LiPo battery packs are designed to look
like NiXX battery packs. One indication of a LiPo battery is the presence of a balance plug
either exiting the battery with small wires and small plug on the end or a small female
plug embedded into the end of the battery pack. If you are unsure of the battery type you
are attempting to use; please consult your local hobby dealer for assistance.
Connectors:
The supplied battery connector is known as HCT-Plug and it is the most common battery
connector in the industry for high current applications and it can be used successfully
with NiXX and LiXX type batteries. If your existing batteries have different connectors than
what is supplied with this system, it is always better (regardless of battery type being
used) to change the connector on your system than to use an adapter, as long as you
are not reducing the current rating of the connector system. This reduces the electrical
resistance in the system and provides the optimal performance.
WARNING: Always ensure the connector polarity is correct ( [+] to [+] and [-] to [-] )
before connecting the battery to the ESC. The Reaktor ESC uses a RED wire for [+] and
a BLACK wire for [-]. If you connect a battery to the ESC with reverse polarity, the ESC
WILL be damaged and this will not be covered under warranty.
Installation:
Installing your ESC and motor is critical for proper operation. You will need to mount your
components securely to a rigid part of the chassis in your vehicle. It is not recommended
to use a hook and loop type material to secure your ESC as this can come loose in wet
conditions and get damaged.
1. Ensure the mounting surface of the ESC and chassis are clean of debris and oils, use
denatured rubbing alcohol to clean the surfaces.
a. You will need to check the mounting integrity periodically to ensure it remains
mounted in the vehicle. Good RC quality double sided tape can be purchased at
your local hobby dealer.
2. Install the ESC so that the ESC itself and its wires are away from moving or sharp
