...INSTALLING AND WIRING YOUR REAKTOR BRUSHLESS SYSTEM
REAKTOR SYSTEM OVERVIEW...
Simple • Capable • Safe
The Radient Reaktor series brushless motors and ESCs form a great power plant to satisfy
your need for speed and performance as an entry level brushless system. Though the Reaktor
system was engineered for value, performance was definitely a factor. We’ve included some
great features for you to help keep your system running in top shape while keeping your
battery upgrade path open since it is compatible with LiPo batteries.
WARNING: ALWAYS ALLOW YOUR MOTOR TO COOL BETWEEN RUNS. EXCESSIVE
ACCELERATION AND AGGRESSIVE DRIVING WILL CAUSE YOUR SYSTEM TO GET
HOT. EXERCISE GREAT CARE WHEN HANDLING YOUR VEHICLE AFTER RUNNING TO
AVOID GETTING BURNED.
Some great features of your new ESC may include:
• All Weather (except the fan on fan equipped models) and dust-proof. The ESC can
work under water for a short time, but its designed for use in and around mud, snow
and puddles.
› If equipped, please unplug the cooling fan when running the ESC in heavy water,
and after running, please clean and dry the ESC to avoid oxidation of the copper
connectors
• Specially designed for RC cars and trucks, with excellent start-up, acceleration and
linear feeling.
• The sensorless system is efficient, durable and reliable.
• ESC’s include the following programmable features
› 2 running modes suitable for different applications (“Forward with brake” mode,
“Forward/Reverse with brake” mode).
› Proportional ABS brake function with 4 steps of maximum brake force adjustment,
8 steps of drag-brake force adjustment.
› 4 start modes (“Punch”) from “Soft” to “Very aggressive” to be suitable for different
Wiring:
5. Connect the 3 motor wires on the ESC. Any order will work for now but may need
adjustment after setting the ESC to the radio. If the motor turns in the wrong direction,
simply swap any 2 motor wires to change its direction.
6. Secure the excess wire using plastic wire ties, away from any moving parts of the
vehicle and so that they will not fall out of the car during running.
7. Plug the ESC wire into the channel 2 port on your receiver, ensure proper polarity
on the wires.
8. Ensure the ESC is OFF and connect your charged battery (up to 3s LiPo).
