2
MOUNTING AND
CONNECTING THE
AMPLIFIER
Use RG-6QS (Quad shield) 75-ohm
coaxial cable, available at your local
RadioShack store, for all amplifier
connections.
Note:
Use only the length of cable
necessary for the connections. Ex-
cess cable causes loss of signal
strength.
Single TV/VCR Connection
1. Using the supplied screws, mount
the amplifier on a wall or base-
board, as close as possible to the
cable box.
2. Connect the output terminal of the
cable box or VHF/FM antenna to
the amplifier’s
CABLE IN
terminal.
3. Connect the amplifier’s
CABLE
OUT
terminal to the 75-ohm VHF
terminal on your TV or VCR. If
your TV has only 300-ohm VHF
terminals, use a 75-to-300 trans-
former (such as RadioShack Cat.
No. 15-1230).
4. Plug the amplifier’s power cord
into a standard AC outlet.
Multiple TV/VCR Connection
1. Using the supplied screws, mount
the amplifier on a wall or base-
board, as close as possible to the
cable box.
