3
4. If desired, tilt the tweeter toward the lis-
tening area. Carefully press down on the
upper or lower frame surrounding the
tweeter to tilt it two steps up or down.
Caution:
When you move the tweeter, do
not touch the thin, vibrating part. Hold
only the outer, hard plastic portion.
5. Replace the grille.
CARE AND MAINTENANCE
Caution:
You might permanently damage
your speaker by cleaning it with a vacuum
cleaner. Use a feather duster or a soft loose
cloth instead.
To enjoy your speaker for a long time:
• Keep the speaker dry. If it gets wet, wipe
it dry immediately.
• Use and store the speaker only in normal
temperature environments.
• Handle the speaker gently and carefully.
Do not drop it.
• Keep the speaker away from dust and
dirt.
• Wipe the speaker with a damp cloth
occasionally to keep it looking new.
Modifying or tampering with the speaker’s in-
ternal components can cause a malfunction
and might invalidate its warranty. If your
speaker is not performing as it should, take it
to your local RadioShack store for assistance.
SPECIFICATIONS
Resonant Frequency ........................ 55 Hz ± 20%
Frequency Response ..................... 65 Hz–25 kHz
Power Handling .................................... 50W RMS
Maximum Power ......................................... 100W
Impedance ............................... 8 Ohms (nominal)
Sensitivity .................................................... 89 dB
Magnet Size ................................... Woofer 6
1
/
2
in
Tweeter 2 × 2
1
/
2
in
Magnet Weight ................................ Woofer 10 oz
Tweeter 2.8 oz
Dimensions (HWD) ...................... 12 × 9 × 3
1
/
2
in
(30.5 × 23 × 9 cm)
Specifications are typical; individual units might
vary. Specifications are subject to change and im-
provement without notice.
Do Not Touch
This Area
Press
Here
Press
Here
