№ NAME QTY

1 Driving rod 1

2 Top armr est rod 1

3 driving choke off rod assy 1

4 choke off rod 1

5 engine 1

6 bolt M6x35 1

7 nut M6 8

knob

nut M8

10 bolt M8x50 2

11 Lower armrest rod 1

wire clip

13 driving tension spring 1

14 back cover 1

15 E retainer ring Φ5 4

16 back cover axle 1

17 back cover t ors ional spring 1

18 bolt M8x16 4

19 nut M8 12

20 left armrest support 1

21 bolt M8x16 4

22 height adjusting rod 1

23 height adjusting tension spring 1

24 screw M6x12 4

25 rear axle pressing plate 2

26 nut M5 2

27 16'' s teel deck 1

28 6'' wheel cover 2

29 washer 8.5*16*1 4

30 fr ont wheel as sy 2

31 fr ont wheel axle assy 1

32 fr ont wheel axle clip 2

33 W circlip 2

34 bolt M8x25 3

35 screw M6x6 2

36 belt cover 1

37 blade 16'' 1

38 blade seat assy 1

washer ￠10.5X￠45X2.5

40 blade bolt 1

41 bolt M6x12 1

42 driving wheel 1

43 key 4×5.5×25 1

44 retainer ring Φ12 2

45 left output gear 1

46 pin 2

47 dust proof cover 2

48 wheel cover 2

49 bearing 6

50 rear wheel assy 2

51 lining Φ13×Φ18×16.6 2

52 right output gear 1

53 lining Φ12.8xΦ18x16 2

54 rear wheel axle ass y 1

55 handle ass y 1

56 bolt M5x10 4

57 height plate 1

58 right armrest support 1

59 height adjusting knob 1

60 return tension spring 1

61 self moving s top plate 1

62 speed changing box 1

63 V belt 1

64 grass bag support assy 1

65 grass bag assy 1

66 washer Φ6×Φ12×1.5 3

67 hanger 1

68 nut M6 1

RD-GLM07 075002 SPARE PARTS

1 crankcase 1

2 speed governing oscillating bar 1

3 speed governing oscillating bar washer 1

4 speed governing oscillating bar locking clip 1

5 oscillating bar oil seal 1

6 oil seal 1

7 oil seal 1

8 intake valve 1

9 valve exhaust 1

10 valve spring 2

11 intake valve srping seat 2

12 oil baffle cover 1

13 Rocker arm assy 2

14 crankcase cover 1

15 Oil level gauge 1

16 speed governing gear assy 1

17 c rankshaft 1

18 timing gear 1

19 camshaft 1

20 crankshaft gasket 1

21 connecting rod assy 1

22 piston 1

23 piston ring 1

24 piston pin 1

25 piston circlip 2

26 t appet 2

27 pushing rod 2

28 locat ion pin 2

29 locat ion pin 2

30 cylinder head gasket 1

31 cylinder head 1

32 flywheel 1

33 flywheel nut 1

34 ignition coil 1

35 ignition bolt 1

36 starter bolt 2

37 fan cover 1

38 breather valve 1

39 oil filter 1

40 return c ham ber gasket 1

41 return chamber cover 1

42 brake assy 1

43 brake spring 1

44 bolt M6x89 2

45 intake gasket

46 carburetor connecting block 1

47 carburetor gasket 1

48 carburetor 1

49 air filter gasket 1

50 exhaust pipe 1

51 air filter assy 1

52 m uffler 1

53 m uffler cover 1

54 speed governing arm 1

55 throttle rod 1

56 micro speed governing spring 1

57 speed governing controller 1

58 return spring 1

59 fuel tank 1

60 starter cover 1

61 start er assy 1

62 oil pipe 1

63 Rocker arm pin 2

64 bolt 15

65 bolt 7

66 bolt 3

67 screw 1

68 cylinder bolt 2

69 cylinder bolt 2

70 c ylinder gasket 1

71 cylinder 1

72 spark plug 1

73 nut 2

74 nut 2

75 nut 3

76 hanger 1

77 circlip 11 1

78 circlip 10 1

79 bolt 1

80 fan 1

81 start er 1

82 ignition support 1

RD-GLM07 075002 engine spare parts list
