Cavity Cartridge Fuse Micro Fuse Description
F35 30 Amp Pink – Sunroof – If Equipped
F36 30 Amp Pink – Rear Defroster – If Equipped
F37 30 Amp Pink – Cummins Diesel Fuel Heater #2 –
If Equipped
F38 30 Amp Pink – Power Inverter 115V AC – If
Equipped
F39 20 Amp Blue – Power Outlet – Special Services
Only
F41 – 10 Amp Red Active Grill Shutter – If Equipped
F42 – 20 Amp Yellow Horn
F44 – 10 Amp Red Diagnostic Port
F46 – 10 Amp Red Upfitter – If Equipped
F49 – 10 Amp Red Instrument Panel Cluster (Except
Fleet Vehicles)
F50 – 20 Amp Yellow Air Suspension Control Module – If
Equipped
F51 – 10 Amp Red Ignition Node Module / Keyless Ig-
nition (Instrument Panel Cluster –
Fleet Vehicles Only)
F52 – 5 Amp Tan Battery Sensor
F53 – 20 Amp Yellow Trailer Tow – Left Turn/Stop Lights
F54 – 20 Amp Yellow Adjustable Pedals
F56 – 15 Amp Blue Additional Diesel Content – If
Equipped
F57 – 20 Amp Yellow Transmission
F58 – 20 Amp Yellow Spare Fuse
F59 – 10 Amp Red SCR Relay – If Equipped
F60 – 15 Amp Blue Underhood Lamp
F61 – 10 Amp Red
(1500 LD Diesel
& Cummins Die-
sel)
PM Sensor – If Equipped
F62 – 10 Amp Red Air Conditioning Clutch
F63 – 20 Amp Yellow Ignition Coils (Gas), Urea Heater
(Cummins Diesel)
F64 – 25 Amp Clear Fuel Injectors / Powertrain
F65 – – Spare Fuse
F66 – 10 Amp Red Sunroof / Passenger Window
Switches / Rain Sensor
F67 – 10 Amp Red CD / DVD / Bluetooth Hands-free
Module – If Equipped
F69 – 15 Amp Blue Mod SCR 12V (Cummins Diesel) –
If Equipped
MAINTAINING YOUR VEHICLE
329
