SERVICING AND MAINTENANCE 431
F46 30 Amp Pink – Fuel Heater
F47 30 Amp Pink – Rear Defroster
F48 – – Spare
F49 30 Amp Pink – Htr Ctrl (Diesel Only)
F50 20 Amp Blue – AUX SWITCH #6 — If Equipped
F51 25 Amp White – FUEL PUMP MOTOR #1 — If Equipped
F52 – – Spare
F53 – 10 Amp Red Supply / Purging Pump – If Equipped
F54 – 15 Amp Blue PCM
F55 – 15 Amp Blue Right HID Headlamp
F56 – – Spare
F57 – 20 Amp Yellow Horn
F58 25 Amp White – FUEL PUMP MOTOR #2 — If Equipped
F59 – 25 Amp Clear Injectors / IGN Coil / Glow Plug Module
F60 – 20 Amp Yellow ECM / PCM / ACT Short Running Valve
F61 – 15 Amp Blue Left HID Headlamp / Spare
F62
60 Amp Blue
40 Amp Green
– Glow Plug (DSL) / LTR Coolant Pump (TRX)
F63 20 Amp Blue – NOx Sensor
F64 – 10 Amp Red PM Sensor – If Equipped
Cavity Cartridge Fuse Micro Fuse Description
8
