434 SERVICING AND MAINTENANCE
F29 – 20 Amp Yellow Mod CRSM (Heat Rear LT)
F30 30 Amp Pink – Mod DTCM / Mod Tailgate
F31 30 Amp Pink – Mod CBC 1 Interior Light
F32 – 20 Amp Yellow RT Spot Lamp — If Equipped
F33 – 10 Amp Red
Assy Overhead Console / Switch 911 / Switch Assist / Heads Up
Display (HUD)
F34 – 15 Amp Blue Frt & RR Ventilated Seat Motor
F35 – 10 Amp Red
Mod Inverter / Mtr Sunshade Sunroof / Mtr Dual Sunroof / USB
Charge Only
F36 40 Amp Green – Mod CBC 2 Exterior Light 1
F37 – – Spare
F38 – – Spare
F39 – – Spare
F40 20 Amp Blue – Dome Pursuit Vehicle — If Equipped
F41 A&B – 15 Amp Blue
Lumbar Support & Pass SW / Mod ICS Sw Bank / HVAC Ctrl / Sw
Bank Upper / Mod Ctrl Steering
F42 A&B – 10 Amp Red
Mod Transfer Case Switch Module (TCSM) / SBW / Electric Park
Brake SW / Overhead Console (OHC) SW / E-Call / Bank 3 SW / Seat
LT & RT Vent / Mod Trailer A&B Tire Pressure / Mod Gateway Trailer
F43 A&B – 10 Amp Red Port Diagnostics / Mod CD / Front & Rear USB
F44 – 20 Amp Yellow
Radio / DCSD / Telematics Box Mod / Fleet Telematics Module
(FTM)
Cavity Cartridge Fuse Micro Fuse Description
21_DT_OM_EN_USC_t.book Page 434
