SERVICING AND MAINTENANCE 439
F64 – 25 Amp Clear Fuel Injectors / Powertrain Control Module / SRV *
F65 – 10 Amp Red MOD Inverter (Wake Up) / Power Port / USB IP / WCPM *
F66 – 10 Amp Red Sunroof / USB Rear *
F67 – 10 Amp Red UCI Port / USB Front
F68 – 10 Amp Red AEB RACAM HTR *
F69 – 15 Amp Blue SCR Module 12 Volt *
F70 – 30 Amp Green Fuel Pump Motor / K09 RLY Coil Feed *
F71 – 25 Amp Clear Amplifier / Active Noise Cancellation *
F72 – — Spare
F73 – 20 Amp Yellow Fuel Transfer Pump *
F74 – 10 Amp Red Backup Alarm *
F75 – 10 Amp Red ATMM / Coil-SCR Module RLY *
F76 – 10 Amp Red Electronic Stability Control *
F77 – 10 Amp Red
Drivetrain Control Module / Front Axle Disconnect
Module / TCM/ STOM
F78 – 15 Amp Blue
Engine Control Module / Powertrain Control Module / AEB
RACM MOD / Feed To AUX PDC Relay Coils/ HRLS
F79 – 15 Amp Blue ID / Clearance Lights
F80 – 10 Amp Red Overhead Console / Assist / 911 *
F81 – 20 Amp Yellow Trailer Tow Right Turn / Stop Lights *
F82 – 10 Amp Red Steering Column Control Module / Cruise Control
Cavity Cartridge Fuse Micro Fuse Description
8
