96 GETTING TO KNOW YOUR VEHICLE
3. From the Released Position, send the
clamps to the Stowed Position by pushing
from the yellow bumper upward.
Stowed Position
4. Fold the rear panel up onto the center panel
(Intermediate Position).
Folded Rear Panel (Intermediate Position)
NOTE:
The vehicle cannot be driven when the Tonneau
Cover is in this position.
5. Fold the rear and center panels up onto the
front panel (Tri-Folded Position).
Tri-Folded Position
Incorrect Folding — Will Cause Damage
Correct Folding — Hold Panels Together
CAUTION!
Make sure the Tonneau Cover clamp and
clamp wire are in the proper stowed position.
If the clamp and clamp wire are not properly
stowed, damage to the Tonneau Cover
material will result.
