1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
125
SURFACE
FINISH:
SURFACE FEATURES: MACHINED PARTS ONLY
T.I.R
.005 PERPENDICULAR .015
FLATNESS .010 PARALLEL
.015
4100
X.X ±0.03
X.XX ±0.015
X.XXX ±0.005
FRACTION ± 1/16
ON ALL
MACHINED
SURFACES
DIMENSIONS:
BREAK ALL SHARP EDGES
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
AND ALL TOLERANCES ARE AS STATED
3rd ANGLE PROJECTION
DO NOT SCALE
R7PT-12AK LW
LBS.
410625
EST. FINISHED
WEIGHT
ORIGINAL JOB NO.
MODEL NUMBERNEXT ASSEMBLY
ANGLES: ±
0.5°
APVD:
M. WEHMEYER
M. TROYER
M. TROYER
2/19/2019
2/19/2019
CKD:
W. CULBERTSON
DWN:
ENG:
2/19/2019
TITLE:
2/19/2019
WINCH ASSEMBLY WITH
LEVELWIND, R7PT-12AK
SIZE:
AF82201
410622
SHT:SCALE:
DWG NUMBER: REV:
PART NUMBER:
NTS OF
1
0
2
B
THIS DRAWING IS THE PROPERTY
OF RAM ITC. THE DESIGN AND DATA
SHOWN INCLUDES PROPRIETARY
INFORMATION THAT DESCRIBES
RAM ITC. PRODUCTS. THE
BORROWER BY RECEIPT AND
RETENTION OF THE DRAWING
AGREES, THAT EXCEPT AS
EXPRESSLY AUTHORIZED IN
WRITING BY RAM ITC., IT WILL (1)
ONLY USE THE DRAWING OR THE
DESIGN AND DATA SHOWN FOR THE
PURPOSE INTENDED BY RAM ITC; (2)
NOT LOAN, REPRODUCE, EXHIBIT OR
DISTRIBUTE THE DRAWING OR ANY
COPY OF THE DESIGN OR DATA
SHOWN FOR USE BY ANY OTHER
THAN RAM ITC., AND (3) UPON
DEMAND RETURN THE DRAWING,
ALL COPIES AND ALL MATERIAL
COPIES THEREFROM.
1.0
MUFFLER, 1-1/2 NPT
1AG10015
-
48
3.8
2" NPT MUFFLER
1AG10016
-
47
.0
1/8 NPT ST Zerk
1
AG12793
-
46
.0
BUNA-N O-RING, 1/8" x 6 1/2" I.D.
1
AG80038
-
45
.2
5/8 X 1 1/4 LONG DOWELL PIN
2AG81012
-
44
.0 MULTISEAL1AG81021
-
43
3.5
SPHERICAL ROLELR BEARING 75x160x37mm
1
AG81022
-
42
2.6
3/4in DIA. x 1 3/4in LONG DOWEL PIN
12AG81024
-
41
2.0
2_1-2 MNPT X 2 FNPT REDUCER BUSHING, CLASS 1502FP01427
-
40
3.4
2" NPT STREET EL
1FP10943
-
39
.1
CLOSE NIPPLE, 1-1/2 M NPT
1
FP99985
-
38
1.2
1-1/2" NPT STREET ELBOW, 90°
1
FP99987
-
37
.1
5_16-18 X 7_8 FHSCS
4
FQ00499
-
36
.1
1/4-20 x 3/4 HHCS
6FQ00525
-
35
.5
1/2-13 X 1-1/2 HHCS
4
FQ02048
-
34
2.6
5/8-11 X 2 HHCS
10FQ04099
-
33
3.6
5/8-11 X 4 HHCS
8FQ04157
-
32
4.4
5/8-11 X 5 HHCS
8FQ04162
-
31
3.1
3/4-10 X 2 HHCS8FQ05017
-
30
5.9
3/4-10 X 2-3/4 HHCS
12FQ05037
-
29
7.1
3/4-10 X 4 1/2 HHCS
10FQ05125
-
28
.0
1/4 LOCKWASHER
6FQ11015
-
27
.1
1/2 LOCKWASHER
4
FQ11202
-
26
.5
5/8 FLAT WASHER
16FQ12747
-
25
1.4
3/4-10 HEX NUT
10FQ12751
-
24
1.4
3/4 FLAT WASHER
28FQ12757
-
23
47.3
CV3 CONTROL VALVE ASSEMBLY
1
AG0811140811122
327.4
ASSEMBLY, AIR MOTOR R5M295 BALANCED PORT ROTARY VALVE, CCW
1
AG0871440871421
9.0 COVER, BEARING END CAP1AG0890640890620
218.2 MACHINING, DRIVE END PLATE, R71AG0915340915319
236.1
MACHINING, BEARING END PLATE, R7
1
AG0915540915518
391.4
ASSEMBLY, GEARBOX 116.46, R7
1
AG09162409162
17
.7 RETAINER, DRUM SHAFT IDLER BEARIING1AG0917640917616
123.9
SIDE FRAME, R7-12MK/AK DRUM WINCH
2AG8015340917715
198.6
ASSEMBLY, DISC BRAKE, R7
1
AG09179409179
14
.9
BRACKET, GEARBOX OIL FILL MOUNTING3AG0921340921313
3.6
HOSE ASSEMBLY, 1-1/2 IN. HOSE W/ 1-1/2 MNPT ENDS, 40 IN. LG
1H952940409529-4012
1.9
Ø7/8 ROPE WEDGE, R7
1AR1080041080011
1063.4
DRUM, Ø16 TALL FLANGE X 12 IN. LG W/BRAKE SURFACE, R7T
1
A04820141048210
676.2
ASSEMBLY, R7 LEVELWIND
1
AR105804105809
281.6 MOUNTING BRACKET, R7 ADJUSTABLE LEVELWIND2AR105814105818
5.8
SPACER, DRIVE SIDE UPPER LEVELWIND MOUNTING3
AR10584410584
7
11.6
SPACER, DRIVE SIDE LOWER LEVELWIND MOUNTING3AR105854105856
73.9
ASSEMBLY, FRL, R7
1
AR10596410596
5
223.0
GUARD ASSEMBLY W/LEVELWIND, R7-12AK
1A0623014106234
11.2 PLUMBING ASSEMBLY, AUTOBRAKE CYLINDER & VALVE BRAKE RELEASE 1
AR10628410628
3
3.1
PLUMBING, LEVELWIND, R7
1
AR106774106772
136.5
ASSEMBLY, AUTOMATIC DRUM BAND BRAKE, R7T
1
AR10783410783
1
Parts List
WT (LBS)
EXPANDED DESCRIPTIONDESCRIPTIONQTYPART NO.DRAW NO.ITEM
REVISION HISTORY
REV DESCRIPTION DATE ECN
0INITIAL RELEASE
2/19/2019
NA
NOTES:
4
15
21
19
41
30
23
1
8
9
8
32256
3225
TORQUE ALL FASTENERS ACCORDING TO RAM PROCESS SPECIFICATION PS-100013
WHERE APPLICABLE.
1.
2.
GREASE ALL BEARINGS WITH MULTI-PURPOSE GREASE.
3.
HALF FILL GEARBOX WITH 90 WEIGHT GEAR LUBE.
4.
THE GUARD ASSEMBLY CAN BE ARRANGED TO ACCOMMODATE A WRTOA
RANGING FROM 0° (VERTICAL) TO 90° (HORIZONTAL).
9
5
38
12
22
37
40
48
4
3
2
39
47
