RAM R7 Series User Manual

EXTENDED
SCALE 1 / 4
SECTION A-A
SCALE 1 / 4
RETRACTED
SCALE 1 / 4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
125
SURFACE
FINISH:
SURFACE FEATURES: MACHINED PARTS ONLY
T.I.R
 .005 PERPENDICULAR  .015
FLATNESS .010 PARALLEL
 .015
42.4
X.X ±0.03
X.XX ±0.015
X.XXX ±0.005
FRACTION ± 1/16
ON ALL
MACHINED
SURFACES
DIMENSIONS:
BREAK ALL SHARP EDGES
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
AND ALL TOLERANCES ARE AS STATED
3rd ANGLE PROJECTION
DO NOT SCALE
R7
RS1123
LBS.
409876
EST. FINISHED
WEIGHT
ORIGINAL JOB NO.
MODEL NUMBERNEXT ASSEMBLY
ANGLES: ±
0.5°
APVD:
M. WEHMEYER
M. TROYER
M. TROYER
2/14/2019
2/14/2019
CKD:
W. CULBERTSON
DWN:
ENG:
2/14/2019
TITLE:
2/14/2019
ASSEMBLY, R7 BAND BRAKE
CYLINDER
SIZE:
AR10619
410619
SHT:SCALE:
DWG NUMBER: REV:
PART NUMBER:
NTS OF
1
0
1
B
THIS DRAWING IS THE PROPERTY
OF RAM ITC. THE DESIGN AND DATA
SHOWN INCLUDES PROPRIETARY
INFORMATION THAT DESCRIBES
RAM ITC. PRODUCTS. THE
BORROWER BY RECEIPT AND
RETENTION OF THE DRAWING
AGREES, THAT EXCEPT AS
EXPRESSLY AUTHORIZED IN
WRITING BY RAM ITC., IT WILL (1)
ONLY USE THE DRAWING OR THE
DESIGN AND DATA SHOWN FOR THE
PURPOSE INTENDED BY RAM ITC; (2)
NOT LOAN, REPRODUCE, EXHIBIT OR
DISTRIBUTE THE DRAWING OR ANY
COPY OF THE DESIGN OR DATA
SHOWN FOR USE BY ANY OTHER
THAN RAM ITC., AND (3) UPON
DEMAND RETURN THE DRAWING,
ALL COPIES AND ALL MATERIAL
COPIES THEREFROM.
AA
.0
1/8 X 1-1/4 COTTER PIN
1FQ00021
-
8
.1
3/4-10 HEX NUT JAM
1FQ12755
-
7
28.0 4IN. BORE 16IN. STROKE PNEUMATIC CYLINDER
1
AG81112
-
6
.1
PIN, BRAKE CYLINDER CLEVIS PIN
1
AG08929408929
5
.9 CLEVIS, BRAKE CYLINDER, R71AG098354098354
2.7 STOP TUBE, R7 BAND BRAKE CYLINDER1AR106164106163
10.4 SPRING, R7 BAND BRAKE CYLINDER
1
AR106174106172
.3 ROD SCREW, R7 BAND BRAKE CYLINDER
1
AR10618410618
1
Parts List
WT (LBS)
EXPANDED DESCRIPTIONDESCRIPTIONQTYPART NO.DRAW NO.ITEM
REVISION HISTORY
REV DESCRIPTION DATE ECN
0INITIAL RELEASE
2/14/2019
NA
NOTES:
29
15
16
EXTENDED POSITION
23 RETRACTED POSITION
6
7
4
5
8
5
4
8
1
7
2
3
4
6
5
7
1.
6-15/16 IN. STROKE. 4IN. BORE CYLINDER
3/8 F NPT
3/8 F NPT
(
.63)
(5.50)
(31.03)
