(30)
+OFFSET/-OFFSET:
programmable
offset
keys
for
repeater
service,
or
channel
stepping.
(31)
CLR:
clears
the
current
entry
in
the
display
(32)
RCL:
recalls
a
previously
stored
test
setup.
(33)
STO:
stores
the
currenttest
setup
into
one
of
the
Com3's
ten
memories
(
0
-
9).
3.3
INITIAL
TURN
ON
Connect
the
rear
panel
AC
line
cord
to
a
suitable
power
outlet
and
turn
the
power
switch
on.
The
front
panel
display
will
light
indicating
power
on.
When
first
turned
on
The
Com
3
should
always
start
out
with
these
settings.
Display
:
450.0000
MHz
Generate
RF:
on
FM:
on
1
KHz:
on
CTS:
off
Ext.tone:
off
Deviation:
on,
1.5
Khz
range
selected
X10K:
on
If
these
conditions
do
not
exist
refer
to
the
trouble
shooting
section.
Com
3's
equipped
with
the
standard
OCXO
will
generate
_
10001
precision
signals
within10
minutes,
Units
equipped
with
the
high
stability
XO
will
produ
.5ppm
accur
after
1
minutes.
When
using
the
Com
3
in
cold
environments
longer
warm-up
times
may
be
required.
DETAILED
OPERATION
OF
THE
COM
3
3.4
GENERATE
RF
To
generate
an
RF
frequency,
type
in
the
desired
frequency
then
touch
the
GENERATE
RF
key.
NOTE:
the
display
always
reads
the
frequency
in
Mhz,
therefore
an
entry
of
10
would
generate
10
Mhz,
an
entry
of
0.1
would
generate
100Khz.
For
frequencies
above
100
MHz,
it
is
not
necessary
to
enter
the
decimal
point.
3.5
RF
OUTPUT
LEVEL
The
output
level
is
controlled
by
a
five
step
attenuator
and
a
variable
attenuator.
The
ranges
available
are;
K
0.110
1.0ጩ/
,1.0
to
10.0
nv
,10.0
to
100ፌሃ.
100
to1,000
ዚዜሃ,1,0001510,000
pv.
To
select
the
desired
range,
touch
the
LEVEL
UP
or
LEVEL
DOWN
key
to
select
the
desired
range.
An
LED
will
light
next
to
the
range
selected.
The
output
can
be
controlled
within
the
range
by
the
control
knob
labeled
MICROVOLTS.
3.6
FM
MODULATION
To
FM
modulate
the
RF
frequency
selected,
touch
the
FM
key.
The
deviation
is
adjustable
by
the
MODULATION:
control
knob.
The
indications
on
the
knob
have
no
reference
to
the
FM
deviation,
they
are
used
for
AM.
modulation.
The
deviation
will
be
displayed
automatically
on
the
LED
bargraph.
3.7
AM
MODULATION
To
AM
modulate
the
RF
frequency
selected,
touch
the
AM
key.
The
percentage
of
modulation
is
adjustable
by
the
MODULATION
control
knob
and
is
variable
from
10
to
100
percent.
3.6
CTS
TONE
GENERATION
The
Com3
will
generate
all
the
standard
CTS
tones
(see
table
3.1).
CTS
can
be
generated
in
either
the
AM
or
FM
modulation
modes,
and
in
conjunction
with
`
the
internal
1Khz
tone
source,
or
an
external
tone
source.
To
generate
a
CTS
tone
touch
the
CTS
key,
enter
the
desired
frequency,
then
press
the
CTS
key
again.
The
display
will
show
the
current
CTS
tone
being
generated.Power
up
default
tone
is
(100.0
Hz).
If
an
improper
tone
is
entered,
it
will
not
be
accepted.
To
return
the
display
to
the
generated
RF
display,
just
touch
the
GENERATE
RF
key,
to
display
the
CTS
tone
touch
the
CTS
key.
The
MODULATION
knob
will
control
the
deviation
of
the
CTS
tone
when
inthe
CTS
mode.
