R&S FSH series User Manual

123
E-02
4
Index
A
Additional accessory (connection, AUX) 40
Audio settings 48
Auto accessory detection 45
AUX (additional accessory, connection) 40
B
Battery
charge 34
external charger R&S HA-Z203 37
BIAS Port 1
direct current input 57
intermediate frequency output (IF Out) 57
BIAS Port 2
direct current input 56
external reference 56
external trigger 56
C
Cable faults (measuring) 108
car adapter 35
charging times 36
Connectors 38
CW Signal (measuring) 77
D
Date format 51
DC connection 44
Default Setup 54
Direct current input 57
direct current input (BIAS Port 2) 56
Direct current inputs (BIAS Port 1/2) 41
GalaxyE_v1-10_3.indd 123GalaxyE_v1-10_3.indd 123 08.04.2009 15:21:5408.04.2009 15:21:54

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
