R&S FSH series User Manual

125
E-02
K
Kensington Lock 44
Key click volume 48
L
LAN connection 61
direct connection 61
LAN network 65
Language setting 50
LAN interface 43
Level (measuring) 77
M
measurement
frequency 81
Measurement
cable faults 108
CW Signal 77
harmonic levels / ratios 83
level 77
power and return loss 90
power measurement using the power sensor
85
return loss 100
transfer function of two-port networks 94
Measurement results
recalling 119
saving 116
Mechanical locking device 44
O
Options
check 60
enable 59
GalaxyE_v1-10_3.indd 125GalaxyE_v1-10_3.indd 125 08.04.2009 15:21:5408.04.2009 15:21:54

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
