Install roller stops at all 4 frame corners
31) Mount control handle at preferred working height on right hand post, making sure throttle cable is not twisted,
tighten all 4 bolts. Take note that 32A/36A model’s equipped with the 22hp RATO, do NOT have the throttle
mounted on the handle, it will be near the engine key assembly.
32) Mount Scale bar, the metal spacer sits behind the bar at base where 2 bolts secure it.
