INTRODUCTION
RANGE ROVER 1.9
1. Cav: The connector pin (cavity) number.
2. Col: The colour of wire populating the connector pin.
3. Cct: Identifies the model or feature which uses the wire. 'ALL' means applicable to all
models in the range fitted with the feature or system in question. In instances where
different models, features or systems require different colour wires to be fitted in a
cavity, each instance of the cavity is included in the pin-out table.
NOTE: Wires may not be fitted to all cavities.
Example – 12 Pin Connector
Where necessary, a table listing the circuit reference numbers against a description of the
model or features which may or may not be fitted can be found at the beginning of the
connector section. A sample of a typical table is shown below.
Cav Col Cct
1GR ALL
2B ALL
Cav Col Cct
2G 58
4 GW 499
4 GB 573
4 GR 574
5LGB 58
6 GB 499
6 GW 573
6 GR 574
8 B 499
Cct Model or Feature
1LHD
2 RHD
3Td6
4V8
5 Heated rear seats
6 NAS vehicles only
