KURULUM / ASSEMBLY BJ105
PARÇA LİSTESİ / LIST OF PART AKSESUAR LİSTESİ / LIST OF ACCESSORY
Tanım /
Code
Ebat / Dimension
Adet /
Pieces
1 1199 x 444 x 18 1
2 445 x 264 x 18 4
3 680 x 445 x 18 1
4 680 x 445 x 18 1
5 680 x 445 x 18 1
6 680 x 445 x 18 1
7 598 x 119 x 18 2
8 257 x 108 x 18 8
9 400 x 80 x 18 8
10 400 x 80 x 18 8
11 202 x 80 x 18 8
12 257 x 185 x 18 2
13 400 x 130 x 18 2
14 400 x 130 x 18 2
15 202 x 130 x 18 2
16 403 x 234 x 3 10
17 444 x 100 x 18 1
18 444 x 100 x 18 1
19 1162 x 100 x 18 1
20 427 x 100 x 18 2
21 368 x 93 x 18 3
22 400 x 60 x 18 3
23 400 x 60 x 18 3
24 313 x 60 x 18 3
25 403 x 345 x 3 3
26 676 x 296 x 3 2
Kavela
A01
Dişli Mil
A02
Gövde
A03
Arkalık Çivisi
A05
3,5x18
A06
4x50
A08
Kulp Vidası
A11
Ray Vidası
A41
Ray 40cm
A45
Kulp
A128
Cam
A131
Silikon Cam Tutucu
A132
2
x71 x60 x60
x187 x52 x62
x13 x52 x13
x13 x1 x11
27 382 x 60 x 18 1
28 313 x 60 x 18 2
