Pull down the lower roof making sure that it is located correctly and clip together.
To align the roofs, side panels and awning rails, turn the handle of the jockey wheel up or down.
Pull down the lower roof making sure that it is located correctly and clip together.
If the locating plates do no line up the easiest way is to raise the roof section as high as it will go
and lower down again. You will find that they then line up perfectly.
Repeat the procedure for the second roof and clip into place. Repeat the procedure for the second
security panel, then slide into place the clips along the roof center.
Adjust the level by use of the jockey wheel, then stabilize by lowering the remaining trailer jacks. (
place them all on wooden or plastic supports ),
