Chapter 3: Using the Web Interface
SSH 50202
TELNET 50302
SNMP 50502
MODBUS 50602
Examples:
• To access Slave 2 via HTTPS, the IP address is:
https://192.168.84.77:50002/
• To access Slave 2 via HTTP, the IP address is:
http://192.168.84.77:50102/
• To access Slave 2 via SSH, the command is:
ssh -p 50202 192.168.84.77
Adding, Removing or Swapping Cascaded Devices
Change a device's cascading mode first before adding that device to a
cascading chain, or before disconnecting that device from the chain.
If you only want to change the cascading mode of an existing chain, or
swap the master and slave device, always start from the slave device.
Note: If the following procedures are not followed, a networking issue
occurs. When a networking issue occurs, check the cascading
connection and/or software settings of all devices in the chain. See
Cascading Troubleshooting.
To add a device to an existing chain:
1. Connect the Raritan device to the LAN and find its IP address, or
connect it to a computer.
2. Log in to this device and set its cascading mode to be the same as
the existing chain's cascading mode. See
Setting the Cascading
Mode
(on page 183).
3. Connect it to the chain, using either a USB or Ethernet cable.
To remove a device from the chain:
1. Log in to the desired cascaded device, and change its cascading
mode to None.
Exception: If you are going to connect the removed device to another
cascading chain, set its cascading mode to be the same as the mode
of another chain.
2. Now disconnect it from the cascading chain.
