AUXILIARY EQUIPM.ENT
7.2,2. FIfiING
AND
REMOVING THE TOOLS
Also see Section 2.3
"Work
safety instructions"
Only
persons
authorized to change tools may fit and remove
them. They must
have
first read and understood
this section
of the operating
instructions.
Refer to the enclosed operating
instructions "CNC-COLOURGRAPHIC-CONTROLLER MULTI-
BEND 9000 for RAS 74.2040'
for detailed instructions
on
operaling the machine.
Open
the upper
cheek
and secure it against lowering by using
two
hardwood
suppoils
in the
right and left side section,
approximately
80
mm x 80 mm x 300 mm long.
wooden blocks on the
left and right-hand side
Tools may
only
be fitted
and
removed
when
the machine
is
switched
off.
RAS
7_4.20-40
MULTIBEND 9OOO
i
i
I
i
I
:
I
l
I
l
I
j
l
September 7, 1993
