Rath 2500-16RC - Base Station Cabinet Mounting (Series 2500-205 B;210 B)

2500-205B, 2500-210B, 2500-12RC, 2500-16RC
Page 11
FRONT VIEW BACK PANEL
BOTTOM VIEW
ø0.20” [ø5.08]
6.00” [152.40]
8.75” [222.25]
6.00” [152.40]
6.00” [152.40]
12.00” [304.8]
15.07” [382.78]
1.00”
[25.47]
12” [304.80]
6.50” [165.16]
R0.25”
[R6.35]
R0.10” [R2.54]
8.75” [222.25]
1.50” [38.10]
1.38” [34.93]
