Rath 2500-16RC - Wall Mount Call Box Diagrams (Series 2100-984 LR)

Page 6
2100-984LR, 2400-805LP, 2100-984LRC1, 2400-805LPC1
Page 7
SWITCH
LED
SPEAKER
RJ11C TELEPHONE LINE
1 2 3 4 5 6 7 8 9
0 #
*
Enter
Record
Play/Pause
Stop
www.rathmicrotech.com
Rath Microtech 800-451-1460
RJ11C
PHONE JACK
J3
BATTERY
BACKUP
24V AC/DC
COVER OUTSIDE COVER INSIDE
BASE INSIDE
5.23” [132.93]
6.63” [168.28]
9.88” [250.83]
3.19” [80.96]
BOTTOM
SIDE
6.38” [161.93]
5.63” [161.93]
7.62” [193.63] 9.60” [243.77]
