Rational UltraVent 61 User Manual

UV-USA_CAN SCC_WE, CM_P V06, 11/2016
3
As optional extras, RATIONAL supplies unit hoods without external exhaust air (UltraVent
®
)
UltraVent
®
exhaust hood with condensation system
The condensation technology in UltraVent
®
absorbs and dissipates steam.
> Electrical connection: 1 NAC 120 V (single phase); 8 ft. cord and 5-15P plug included (not connected).
> Power rating 450 W.
> Extraction rating max. 31,700 ft
3
/h (900 m
3
/h).
> Noise level: Stage 1: 65 dBA, stage 2: 70 dBA
> UltraVent
®
is not ducted to a ventilation and air conditioning system. UltraVent
®
is also not connected to
the ventilation system.
> Due to the condensation effect of UltraVent
®
the exhaust air requirement can be reduced by 953 ft
3
/h
(27 m
3
/h) per kilowatt of rated consumption.
> Relative exhaust humidity is reduced to between 37% RH and 4% RH, hence it's below ambient humid-
ity. This means that UltraVent
®
dries the ambient air due to the lower humidity and the somewhat higher
exhaust temperature.
> The UltraVent
®
exhaust hood with condensation system should only be used on units with standard right
hinging doors.
> Local requirements must be complied with; UltraVent
®
exhaust hood has been designed and UL approved
for the extraction of grease free vapors.
WARNING
Check with local codes etc. for acceptance prior to ordering or installation. (If UltraVent
®
are ordered or
installed in NY City, RATIONAL is not responsible for acceptance).
UltraVent
®
appliance sizes
Type 61
6 x 1/1 GN
Type 62
6 x 2/1 GN
Type 101
10 x 1/1 GN
Type 102
10 x 2/1 GN
Electric (no Combi-Duo) X X X X
UltraVent
®
connection diagrams – see connection diagrams.
For use with electric models only 61, 62, 101 and 102.
Not used with Combi-Duo
Approvals:
File: E237079
Tested in accordance with UL710B / NFPA 96, Chapter 13
