UV-USA_CAN SCC_WE, CM_P V06, 03/2016
6
Item Description Wiring Part nos.
diagram
1. Transformer Tr1 3037.0254
2. Pressure switch D1 3017.1014
3. Relay 110V 1U Rel1 40.04.302
4. Impulse relay Rel5 40.04.231
5. Time Relay Rel4 3035.0493
6. Relay 24V 2U Rel2 40.04.303
7. Relay 24V 2U Rel3 40.04.303
8. Bridge rectifier Br 1 40.03.367
9. Fuse 0,315A F2 + F3 3019.0135
10. Fuse 6,3A F1 3019.0122
11. Transformer 110>24V Tr2 3037.0254
12. Mini contactor 24V K3 40.04.306
13. Contactor 24V K1 40.04.305
14. Contactor 24V K2 40.04.305
15. Fuse 6,3A F4 to F7 3019.0122
16. Capacitor 14 μF C1,C2 40.04.229
17. Capacitor 40 μF C3,C4 40.04.230
Description Part nos. Qty.
Magnet Y1 (solenoid) 3035.0494 1
Main switch T1 40.04.356 1
LED green LED3 40.04.308 1
LED red LED2 40.04.166 1
LED yellow LED1 40.04.165 1
Extractor fan, size 61/101 60.72.701 2
Extractor fan, size 62/102 60.72.701 2
Fat filter (left side) 60.72.440 1
Fat filter (right side) 60.72.441 1
Fiber media filter 60.72.556 1
11
2
3
4
5
6
7
9
10
1
8
12
13
14
15
16
17
A
