SQUARE DINING TABLE

Page 5 of 6

STEP 1

Parts Required

NOTE: Only tighten bolts halfway

A. Table Top x1

B. Leg Panel x2

C. Short Panel x2

E. Bolt M6x20 x4

F. Bolt M6x40 x8

G. M6 Hex Nut Cap

x12

H. M6 Spring Washer

I. M6 Washer x12

J. M6 Washer x8

STEP 2

Parts Required

Note: Adjust the balance of the table. Then tighten all bolts to 100%.

Install Glass top onto the top of the table.

Assembled Result

from STEP1

D. Glass top x1
