Foreword
General Data U.S Metric
Weight with Winch and Mulcher 14,800 lb 6,786 kg
Length with Winch and Mulcher 172" 437 cm
Height 103.3" 262.4 cm
Width 77.4" 196.6 cm
Engine 99.2 hp Kubota 73.97 kW Kubota
Fuel Type Diesel Diesel
Track Width 18" 450 mm
Hydraulic System 39 gpm @ 5,500 psi, High Flow Pump 147.6 L/min @ 37,921 kPa, High Flow Pump
Ground Pressure with Winch and Mulcher 5.25 psi 36.2 kPa
Travel Speed - High/Low 5.9 mph / 3.6 mph 9.5 km/h / 5.8 km/h
Predator Mulcher Head FM100-6R FM100-6R
Weight 2,350 lb 1,066 kg
Overall Width 83” 211 cm
Rotor Diameter 16.75" 42.55 cm
Rotor Speed 2,000 rpm 2,000 rpm
Drive Belt Gates® Polychain GT Gates® Polychain GT
Cutting Width 71” 180 cm
Max Mowing Height 113.1" 237.3 cm
Teeth 36 36
A Description of the Machine
The Rayco C100R (Crawler 100 hp Rubber Track Machine) is
designed for your maximum benefit for every dollar spent. The
machine is constructed for durability and easy maneuvering.
Each crawler track is driven by an independent hydrostatic
transmission. The loader and rear auxiliary outputs are driven
by a hydraulic system.
All controls, both hydrostatic and hydraulic, are manipulated
by joysticks. These controls are self-centering.
The C100R is equipped with a 99.2 hp Kubota engine
and Rayco’s exclusive Super Flow closed loop, hydraulic
system, providing 39 gal/minute at 5,500 psi to the FM100
mulcher head.
To extend service intervals, the C100R features an advanced
forestry cooling system which is easy to maintain and will
extend service intervals, even when operating in the most
extreme conditions. High capacity coolers allow operation
in the hottest ambient temperatures. Debris screens filter out
most of the contaminants that plug radiators and are easily
removed for routine cleaning.
The C100R model features a higher ground clearance
and a heavier undercarriage. The C100R’s larger chain
and wider pads provide extra floatation and traction and a
longer service life.
