Rayco RG55T-R User Manual

RG55T-R Operation • Service • Maintenance
800.392.2686
63
Hydraulic Adapter Kit 804352A Rev F
ITEM QTY PART # DESCRIPTION
1 10 REF FF6400-04-06 (04 MORFS X 06 MORB)
2 7 REF FF6801-04-06 (90° 04 MORFS X 06 MORB)
3 1 REF FF6400-08-08 (08 MORFS X 08 MORB)
4 1 REF FF6802-04-06 (45° 04 MORFS X 06 MORB)
5 1 REF FF6804-04-06-04 (TEE 04 MORFS X 06MORB X 04 MORFS)
6 1 REF FF6500-04-04 (90° 04 MORFS X 04 FORFS SWIVEL)
7 4 REF FF6801-06-06 (90° 06 MORFS X 06 MORB)
8 1 REF FF6802-08-08 (45° 08 MORFS X 08 MORB)
9 - - INTENTIONAL BLANK
10 1 REF 4501-16-16 (90° 16 BT X 16MP)
11 3 REF FF2501-04-04 (90° 04 MORFS X 04 MP)
12 5 REF FF6400-04-04 (04 MORFS X 04 MORB)
13 3 REF FF6801-04-04 (90° 04MORFS X 04 MORB)
14 2 REF
FF6804-04-04-04 (TEE 04 MORFS X 04 MORB X 04
MORFS)
15 2 REF FF2501-06-06 (90° 06 MORFS X 06 MP
16 1 REF 4601-16-10 (90° 16 BT X 10 MORB)
17 2 REF TBC150 (T-BOLT CLAMP)
18 3 REF FF6802-06-06 (45° 06 MORFS X 06 MORB)
19 2 REF
199-FF3800-0402-ORING (04MORFS-02MBSPP-ORING
ONLY NO RETAINING RING)
20 2 REF
FF6602-04-04-04 (TEE 04 MORFS X 04 FORFS SWIVEL X
04 MORFS)
21 2 5504-04-04F FEMALE ELBOW 90° 04FNPT X 04FNPT
22 1 205-104 CONNECTOR-5/16” BARB X 1/4 MNPT
23 2 6400-05-06 CONNECTOR -5MJIC -6MOR
24 1 9605-06-12x1.25 CONNECTOR -6MJ-12MMX1.25MMT
25 1 9500-12MM WASHER 12MM
26 1 5406-C-6 CAP-6FP
27 1 203-104 3/16” HOSE BARB X 1/4” MALE NPT
28 4 REF
199-FF3800-0606-ORING (06MORFS-06MBSPP-ORING
ONLY NO RETAINING RING)
29 2 REF
199-FF3800-0404-ORING (04 MORFS-04MBSPP-ORING
ONLY NO RETAINING RING)
30 2 REF
FF6602-06-06-06 (SWIVEL RUN TEE 06 MORFS X 06
FORFS SWIVEL X 06 MORFS)
31 4 REF FF6500-06-06 (90° 06 MORFS X 06 FORFS SWIVEL)
32 - - INTENTIONAL BLANK
33 1 REF 5500-04-02F (90° 04 MP X 02 MP)
