Raymarine C120W - Flush Mounting Procedures

4.2Flushmounting
ThestandardmethodformountingaC-Seriesdisplayisaush
orpanelmountingarrangement.
Beforemountingtheunit,ensurethatyouhave:
•Selectedasuitablelocation
•Identiedthecableconnectionsandroutethatthecableswilltake
•Detachedthefrontbezel
D11193-1
1.Checktheselectedlocationfortheunit.Aclear,atareawith
suitableclearancebehindthepanel,isrequired.
2.Fixtheappropriatecuttingtemplatesuppliedwiththeproduct,to
theselectedlocation,usingmaskingorself-adhesivetape.
3.Usingasuitableholesaw(thesizeisindicatedonthetemplate),
makeapilotholeineachcornerofthecut-outarea.
4.Usingasuitablesaw,cutalongtheinsideedgeofthecut-outline.
Locationandmounting
45
