5.5Productdimensions-speak

ers

ThedimensionsforthePassiveandActivespeakersareshownbelow.

118.5mm(4.67in)

112.5mm(4.43in)

18.3mm(0 .72in)

26.4mm(1.04in)

25mm(0 .98in)

30 .6mm(1.20in)

TheP assivespeakerincludesaﬁtted2m(6.56ft)audiocableterminatedwithamaleRCAplug.

TheActivespeakerincludesaﬁtted2m(6.56ft)powercableterminatedwithaspadeconnectors.
