Raymarine Raymic - Mounting Plate Installation; Technical Specification - Wired Handset (Raymic)

1
Splash-proofdustcapwithlanyard
2Mountingplatefixingsx3
3
Mountingplatenut
4Mountingplate
5Mountingplategasket
6
Extensioncable
1.ChecktheselectedlocationfortheMountingplate,aclearflat
areaisrequired.
2.Usingapencil,offeruptheMountingplatetothedesired
locationandmarkthelocationofthescrewholesandthe
centerholeonthemountingpanel.
3.Drillthemountingholesusingasuitablesizedrillbit.
4.Drillthecenterholeusinga25mm(1in.)holecuttingsaw.
5.Pulltheconnectorendofthecablethroughtheholeinthe
mountingsurface.
6.PlacetheMountingplategasketovertheendoftheconnector.
7.Withtherecessedsidefacingawayfromthemountingpanel,
placetheMountingplateovertheendoftheconnector.
8.PlacethelanyardendoftheSplash-proofdustcapover
theconnector,ensuringthelanyardsitsintherecessinthe
Mountingplate.
9.PlacetheMountingplatenutovertheconnectorandtighten
clockwiseusinga13/16in.(21mm)socketwrench,being
carefulnottodamagetheplasticnutbyovertightening.
10.SecuretheMountingplatetothemountingsurfaceusingthe
suppliedscrews.
11.AttachtheHandset/Fistmicconnectortothecableconnector
androtatethelockingcollarclockwisetosecure.
12.Connecttheoppositeendofthecabletotherequired
connectoreitherontheBasestationortoanotherpass-through
panelmountingplateconnector.
Note:Drillbit,tapsizeandtighteningtorqueisdependenton
thethicknessandtypeofmaterialtheunitistobemountedon.
Operationinstructions
Foroperationinstructionsforyourhandset,refertothe
documentationthataccompaniesyourRadio.
Allproductdocumentation
isavailabletodown-
loadfromtheRaymarine
website:www.rayma-
rine.com/manuals
•Ray60/Ray70Installation
andoperationinstructions
documentnumber:81356
•Ray90/Ray91Installation
andoperationinstructions
documentnumber:81377
Technicalspecification—Wiredhandset
(Raymic)
ThefollowingtechnicalspecificationsapplytotheWiredhandset.
Operatingtemperature
-25ºC(-13ºF)to+55ºC(131ºF)
Storagetemperature
-25ºC(-13ºF)to+70ºC(158ºF)
Relativehumidity
95%
WaterproofingIPx6&IPx7
Maxspeakerpower
output
1W(16Ω)
VHFradiocompatibility
•Ray60
•Ray70
•Ray90/Ray91
4
Raymicwiredhandsetinstallationinstructions
