Table N: Certified Stainless Steel Terminations and Adaptors - Category IV
Model No.
M&G Duravent – “Fas-N-Seal”
Air Intake Terminal Vent Terminal Vent Pipe Vent Adapter
2505
810003447
*D-15 10”
(006650)
10” Fas-N-Seal
6” to 36”
None Required
3005
3505
4005 810003488
*D-15 12”
(007001)
12” Fas-N-Seal
6” to 36”
Model No.
Heat Fab – Saf-T Vent EZ Seal
Air Intake Terminal Vent Terminal Vent Pipe Vent Adapter
2505
91014TERM 91090TEE
10” Saf-T-Vent
6” to 48” Lengths
91001MAD
3005
3505
4005 91214TERM
*D-15 12”
(007001)
12” Saf-T-Vent
6” to 36” lengths
91201MAD
Model No.
Z Flex – “Z Vent”
Air Intake Terminal Vent Terminal Vent Pipe Vent Adapter
2505
2SVEE1090 2SVSRTX10
10” Z Vent
6” to 36” Lengths
2SVDSA10
3005
3505
4005 2SVEE1290 2SVSRTX12
12” Z Vent
6” to 36” Lengths
2SVDSA12
*D-15 Vent Terminal MUST be ordered from Raypak
The XTherm (2505-4005) are supplied with an integral Fas-N-Seal vent connector. The installer must use a
specific vent starter adapter (supplied by the vent manufacturer).
WARNING: Use only the materials, vent systems
and terminations listed in Table P. DO NOT mix
vent systems of different types or manufacturers,
unless listed in this manual. Failure to comply could
result in severe personal injury, death, or substantial
property damage.
NOTE: The XTherm heater is supplied with a vent
connector that MAY require a specific vent starter
adapter to mate to certified Cat IV stainless steel
vent materials (see Table N below). This vent start-
er adapter is supplied by the vent manufacturer to
adapt to the various venting systems.
NOTE: Installation of a stainless steel vent systems
shall adhere to the stainless steel vent manufactur-
er’s installation instructions supplied with the vent
system. Please contact the vent manufacturer with
any questions.
NOTE: The following stainless steel vent manu-
facturers are certified for us on these heaters. DO
NOT use any manufacturer of stainless steel vent
systems not listed here. M&G Duravent (FasNSeal
Vent), Heat Fab (Saf-T-Vent EZ Seal) and Z Flex
(Z-Vent).
