9
REPAIR AND MAINTENANCE
1 (E100 only, other
models go to Step 2)
Loosen the brake pad bolt and
remove one brake pad.
❑ Front Tire Replacement
Tools required: 10mm wrench, two (2) 17mm wrenches and a flathead screwdriver.
2 Using two 17mm wrenches,
loosen the front axle bolts by
turning the wrenches counter
clockwise.
3 Remove wheel and replace
tire. To reinstall wheel, reverse
these steps. Helpful hint: You
may need to use a flathead
screwdriver to center the axil
and the bolts.
