29
01401
01270
01402
01403
01273
01403
01409
01700-110
01404
01406
01408
01270
01407
01411
01060-1
01194
01193
01191
01192
01196
01195
01051-6
TURBO
01060-1
01076-RTR
01085-RTR
01102-2
01259-8STD
01295
01123
01060-1
01162-14RTR
01150-14STD
01130-1402
01211
01689
01151-7
01111
01116
01197
01410
01146-3RTR
01051-6 Glowplug CP-02 Turbo No.6
01060-1 Set hex. screws engine
01060-1 Set hex. screws engine
01076-RTR Cooling head
01085-RTR Combustion chamber Turbo
01102-2 Head shims 0.2mm
01111 Wrist pin clips
01116 Wrist pin
01123 Conrod
01130-1402 Carter
01146-3RTR Piston/liner with conrod
assembled
01150-14STD Main bearing
01151-7 Front bearing 7x19
2RS(rubber shield)
01162-14RTR Crankshaft
01211 Wrist pin carburettor
01295 Gasket engine/manifold
01689 O-ring shaft carb. carter
01259-8STD Carburettor 7mm
01270 O-ring
01273 Intake fuel-pipe
01401 Main needle
01402 Main needle holder
01403 Alu rings
01404 Air screw
01406 Dust protection
01407 Idle needle
01408 Servo lever carburettor
01409 Slide
01411 Carburator body 7mm
01700-110 Outer O-ring carburetor
ENgINE
CARBURETOR
01197 Rear Cover
01410 O-ring for rear cover
STANDARD
01191 Rear cover Pullstart
01192 Start axle pullstart
01193 One Way pullstart
01194 pullstart assembly
01195 Driving pin 5x2,55mm
01196 Spring
PULLSTART
STANDARD ENgINE
PULLSTART ENgINE
