CH4
OUTPUT
TO TV
SMART ANTENNA IN
ANTENNA IN
CH3
TV
ANTENNA
ANTENNA IN
ANTENNA OUT
CH3
CH4
VIDEO
AC~120V
R
AUDIO
L
Step 2: Connections
CH4
OUTPUT
TO TV
SMART ANTENNA IN
ANTENNA IN
AC~120V
CH3
R
AUDIO
L
TV
ANTENNA
VIDEO
Connect your existing antenna cable to the ANTENNA IN jack
of the Converter Box.
Connect the RF coaxial cable (supplied) from the OUTPUT TO
TV jack of the Converter Box to the ANTENNA jack of the TV
set.
Slide the CH3/CH4 selector on the back of the Converter Box to
the channel that is not in use in your area. The Converter Box
will send its video signal to either Channel 3 or 4 on your TV.
Connect the Audio/Video cables (not supplied) from the Audio
/Video OUT jacks (yellow, white, red) of the Converter Box to
the Audio/Video IN jacks on the TV set. If there are more than
two sets of Audio/Video jacks on the TV set, connect only either
INPUT1 or INPUT2 to those of your converter box.
O p t i o n 2 : I f you also need to connect your VCR
1
4
5
3
From antenna
AC120V
1
2
3
4
Back of the RCA converter box
VCR
From antenna
1
2
3
4
AC120V
6
Connect your existing antenna cable to the ANTENNA IN jack
of the Converter Box.
Connect the RF coaxial cable* (supplied) from the OUTPUT TO TV
jack of the Converter Box to the ANTENNA IN jack of the VCR.
Connect the RF coaxial cable* (not supplied) from the
ANTENNA OUT jack of the VCR to the ANTENNA IN jack of the
TV set.
Slide the CH3/CH4 selector on the back of the VCR to the
channel that is not in use in your area. The VCR will send its
video signal to either Channel 3 or 4 on your TV.
Slide the CH3/CH4 selector on the back of the Converter Box to
the channel that is not being used by the VCR; e.g., if you set the
VCR selector to CH3, slide the Converter Box selector to CH4.
Connect the AC power cable of the Converter Box to a
suitable wall outlet.
* You can also use Audio/Video cables (similar to option 1) if
the connection jacks are available on the VCR and TV.
1
2
3
4
5
6
5
DTA800B1_QSG_EN_V1_0.pdf p.2
AUDIO IN
L R
VIDEO IN
(Optional)
Tip: Using the optional Audio/Video cable
connection provides better picture quality
in case your TV set has Audio/Video input available.
Connect the AC power cable of the Converter Box to a
suitable wall outlet.
5
2
Option 1: Basic connection to TV
Note:
The SMART ANTENNA IN jack lets you connect
a Smart Antenna. Refer to the antenna’s user manual
for proper connection.
Smart Antenna provides improved reception. For more
information, please consult your TV dealer.
Note: You may choose to connect the RF coaxial
cable to TV, or Audio/Video cables to TV,
or both the RF coaxial and AV cables to TV.
60Hz
60Hz
