PROFESSIONAL AUDIO MIXER
15
SPECIFICATIONS / TECHNNISCHE DATEN
FMX-1202 FMX-1602
Inputs Mic / Line (Mono) 4 / 4 8 / 8
Inputs Mic / Line (Stereo) 2 / 8 2 / 8
Total Inputs 22 30
Faders 60 mm 60 mm
Input Impedance - Mic (balanced) 1.3 kohms 1.3 kohms
Input Impedance – Channel Insert Return - 2.5 kohms
Input Impedance - All other inputs >10 kohms >10 kohms
Input Sensitivity – Mic -55 dBu -55 dBu
Input Sensitivity – Line (Mono/Stereo) -35 dBu / -20 dBu -35 dBu / -20 dBu
Output Impedance – Tape 1.0 kohms 1.0 kohms
Output Impedance – Effect Returns or Aux 10 kohms 10 kohms
Output Impedance – All other outputs <100 ohms <100 ohms
Signal-to-noise Ratio >= 90 dB >= 90 dB
Crosstalk >= 85 dB >= 85 dB
Frequency Response 20 Hz – 60 kHz 20 Hz – 60 kHz
THD < 0.05% < 0.05%
Maximum Level Main L/R +28 dB +28 dB
Maximum Level Sub 1/2, Mono, Aux Send +20 dB +20 dB
Maximum Level Tape Out -1.8 dB -1.8 dB
Maximum Level Headphone Output 100 mV / 40 ohms 100 mV / 40 ohms
Channel High EQ 12 kHz, +/-15 dB 12 kHz, +/-15 dB
Channel High Mid / Mid EQ (Mono) 3.0 kHz, +-12 dB 3.0 kHz, +-12 dB
Channel Mid EQ (Stereo) 2.5 kHz, +-12 dB 2.5 kHz, +-12 dB
Channel Low Mid EQ - 800 Hz, +-12 dB
Channel Low EQ 80 Hz, +-15 dB 80 Hz, +-15 dB
Low Cut 18 dB/octave at 75 Hz 18 dB/octave at 75 Hz
Phantom Power +48 V DC +48 V DC
Power Requirement 120/220-240 V AC
50-60 Hz
120/220-240 V AC
50-60 Hz
Power Consumption 22 W 25 W
Dimensions (W x H x D) in mm 305 x 354 x 72 411 x 354 x 72
Weight 4.7 kg 5.7 kg
