Ventilation to the room that houses the fire must meet the requirements of NZS5261.
Ventilation
Real Fires are designed for installation into an existing masonry fireplace and chimney. Prior to installation the
fireplace should be measured and a suitable size Real Fire selected. In most situations the fireplace will require
masonry alteration to accommodate the firebox. See installation drawing.
The chimney will need to be inspected for suitability and checked for draw. Ensure it complies with a minimum
height of 2.4 Metres. The top of the chimney is a minimum vertical clearance of 900mm from the roofline and
2 Metre horizontal clearance from any roofline or any other part of the building. See cowl clearance drawing.
The chimney should be swept prior to installation.
Fireplace cavity and chimney inspection
Installation of a Real Fire into a new masonry chimney may require installation with an insulation kit and flue kit.
This will also involve leaving the fireplace opening 1200mm high to allow installation. The method of installation is
as per timber frame installations. Please consult Real Fires in this situation for advice prior to installation.
New Masonry Block Chimney
A non combustible Hearth must be provided in front of the Real Fire unless the flooring in front of the fire is non
combustible. The minimum size is 300mm out from the fire and 150mm each side wider than the fire.
Hearth
It is important to confirm the height the fire is going to be installed above the floor. This is usually the hearth
height. For example if the hearth is going to be 100mm high then the base of the fireplace cavity usually needs to
be the same height. (note- some elevated installations specify the fire higher than the hearth).
It is important that the base of the cavity is plastered smooth and level.
Height of re from oor
Model 800
Installation Into Existing Masonry Fireplace
